LifeLine Chain Rivet Extractor

LifeLine Chain Rivet Extractor

The LifeLine Chain Rivet Extractor is a must for every home mechanic. Constructed from durable steel, this chain tool is small enough to take with you when you’re on the move.

Features:



•
• Durable steel construction
• Rubberised handles for grip
• Comes with one replacement splitting pin
• Adjustable chain support screw prevents damage to the chain and the tool
• Suitable for all chains from 6, 7, 8, 9 and 10 speed chains



Instructions for proper use:



1.
2. Back off the handle to make room for the chain to be fitted to the tool
3. Back off the adjustable support screw at the rear of the tool
4. Place the chain on the rear teeth of the tool (nearest the adjustable support)
5. Tighten the adjusting support screw until it comes firmly into contact with the back of the chain
6. Turn the handle of the tool gently until the tool pin comes into contact with the centre of the chain pin
7. If the two pins are not lined up, back off the handle and re-position the chain in the tool
8. Repeat steps 5 and 6 until the two pins are aligned
9. Now firmly tighten the handle to push the pin out, splitting the chain
10. The only time you would use the front teeth on the tool is to loosen a tight link slightly – If you try to split a chain using them, you will break them off
